|Place of Origin:||CHINA|
|Minimum Order Quantity:||1|
|Packaging Details:||Wooden Case Packaging|
|Delivery Time:||3-50 Working Days|
|Supply Ability:||1000 SET|
|Filling Volume:||1000ml(could Be Customized Based On Requirements)||Number Of Filling Heads:||16|
|Accuracy:||Up To ±1%||Machine Dimension(L*W*H):||2400mm*1350mm*2500mm|
|Power:||5KW||Power Supply:||AC 380V,50Hz;or AC 220V,50Hz (Customized)|
|Air Operated Source:||0.4-0.6Mpa Clean And Stable Compressed Air||Weight:||About2000kg|
Hand Sanitizers Liquid Piston Filler,
Liquid Piston Filler 80bpm,
1000ml Liquid Piston Filler
Is suitable for various viscous and non viscous and corrosive liquid. This daily chemical filling line is widely used in the filling of shampoo, laundry detergent, hand sanitizer, disinfectant, alcohol and other products.
Adopts world-class electric components with microcomputer (plc) automatic control function, compact structure, long service life of parts, easy maintenance, safe and reliable, low noise, simple operation, accurate and convenient measurement adjustment.
1.Accurate measurement: adopt servo control system, ensure the piston can always reaches constant position.
2. Variable speed filling: in filling process, when close to target filling capacity can be applied to realize speed slow filling, prevent the liquid spill bottle mouth cause pollution.
3. Convenient adjustment: replacement filling specifications only in touch screen can be changed in parameters, and all filling first change in position, fine-tuning dose it in touch screen adjustment Adopt servo motor to descend.
4. Daily chemical filling production line adopts microcomputer PLC automatic control.
5. All parts contacting the material and liquid are made of SUS304/316 stainless steel, the whole machine is beautiful and generous. Meet the GMP standard.
Main technical parameters
|02||Filling volume||1000ml(could be customized based on requirements)|
|03||Number of filling heads||16|
|05||Accuracy||Up to ±1%|
|08||Power supply||AC 380V,50Hz;or AC 220V,50Hz (Customized)|
|09||Air operated source||0.4-0.6Mpa clean and stable compressed air|
Major technical components
(1) Under stable voltage, the machines' quality that we sold will be guaranteed for 1 year
(2) Long time technology will be supplied.
(3) We can dispatch our engineer to your side for installing and debugging machines. Engineer's round-trip tickets, accommodation, and your side traveling fee will be charged by you. Engineer's salary will be USD60.00/day/person.
We can also supply training process for your engineers who come to china, so you can fit and debug machines by yourself.
