16 Head 220 V 60Hz 15A Automatic Liquid SERVO Bottling Piston Filler Multiple filling nozzles as 6, 8, 12 or 20

16 Head 220 V 60Hz 15A Automatic Liquid SERVO Bottling Piston Filler Multiple filling nozzles as 6, 8, 12 or 20

  • 16 Head 220 V 60Hz 15A Automatic Liquid SERVO Bottling Piston Filler Multiple filling nozzles as 6, 8, 12 or 20
  • 16 Head 220 V 60Hz 15A Automatic Liquid SERVO Bottling Piston Filler Multiple filling nozzles as 6, 8, 12 or 20
  • 16 Head 220 V 60Hz 15A Automatic Liquid SERVO Bottling Piston Filler Multiple filling nozzles as 6, 8, 12 or 20
  • 16 Head 220 V 60Hz 15A Automatic Liquid SERVO Bottling Piston Filler Multiple filling nozzles as 6, 8, 12 or 20
  • 16 Head 220 V 60Hz 15A Automatic Liquid SERVO Bottling Piston Filler Multiple filling nozzles as 6, 8, 12 or 20
16 Head 220 V 60Hz 15A Automatic Liquid SERVO Bottling Piston Filler Multiple filling nozzles as 6, 8, 12 or 20
Product Details:
Place of Origin: CHINA
Brand Name: STRPACK
Certification: ISO,CE
Model Number: STR
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Price Negotiable
Packaging Details: Wooden Case Packaging
Delivery Time: 3-50 Working Days
Payment Terms: TT/LC
Supply Ability: 1000 SET
Contact Now
Detailed Product Description
Power Supply: AC 220V ;50Hz Or 380V; 50Hz Power: 1.5Kw
Filling Volume: 5-60ml, 10-125ml, 25-250ml, 50-500ml, 100-1000ml, 250-2500ml And 500-5000ml. Number Of Filling Nozzles: Multiple Filling Nozzles As 6, 8, 12 Or 20
Filling Accuracy: 99%. Compressed Air: 0.4 - 0.6Mpa.

16 Head 220 V 60Hz 15A Automatic Liquid SERVO Bottling Piston Filler Multiple filling nozzles as 6, 8, 12 or 20



STRPACK manufactures different liquid bottle fillers that serve different purposes. To choose the best bottle filling machine for your application you must take into consideration:

- Production Speed
- Viscosity of your product (liquid, water, other)
- Characteristics of your products (Contains particles, It's flammable, Foamy, among others)
- Container characteristics, shape, material, etc...

We offer the following bottle filling principles:

- Overflow filler: Used to fill low viscosity products, can handle foamy and non foamy products, speeds up to 150 bpm. Great value filling machine because of the production speeds obtained with small investment, the limitation is the viscosity of the products. Produces a cosmetic level fill.

- Piston filler: Used to fill from low to high viscosity products, and can handle products with particles with the right options. They can handle speeds up to 120 bpm and are capable of filling anything an overflow machine can but the cost of the machine is higher. The speed on this filling machine is higher for viscous products because the thin products tend to overflow if filled to fast. Several piston sizes may be required to fill a wide range of products.

- Pump Filler: Used to fill from low to high viscosity products. They can handle products with particles with the right options, and speeds up to 160 bpm. These fillers are capable of filling anything an overflow machine can but the cost of the machine is higher. More expensive than a piston filler but does not require any change of parts to fill from a few ml to gallons.

Application

  • Water Liquid Bottling Piston Filler
  • Fruit Juices Liquid Bottling Piston Filler
  • Extracts Liquid Bottling Piston Filler
  • Liquid Tea Liquid Bottling Piston Filler
  • Liquid Coffee Liquid Bottling Piston Filler
  • Food Coloring Liquid Bottling Piston Filler
  • Vegetable Oil Liquid Bottling Piston Filler
  • Milk Liquid Bottling Piston Filler
  • Wine Liquid Bottling Piston Filler
  • Tomato Juice Liquid Bottling Piston Filler
  • Some Salad Dressings Liquid Bottling Piston Filler
  • Perfumes Liquid Bottling Piston Filler
  • Essential Oils Liquid Bottling Piston Filler
  • Ink Liquid Bottling Piston Filler
  • Thin Liquid Soap Liquid Bottling Piston Filler
  • Shampoo Liquid Bottling Piston Filler
  • Light Makeup Remover Liquid Bottling Piston Filler
  • Motor Oil Liquid Bottling Piston Filler
  • Urethane Liquid Bottling Piston Filler
  • Silicone Liquid Bottling Piston Filler
  • Urine Liquid Bottling Piston Filler
  • Alcohol Liquid Bottling Piston Filler





Technical parameter:





NO. Items Performance
01 Power Supply AC 220V ;50Hz or 380V; 50Hz
02 Power 1.5Kw
02 Suitable containers Container mouth diameter: ≥Φ18mm
Container height:100mm-300mm
Container diameter:30mm-100mm
03 Number of filling nozzles 12 (may customized)
04 Productivity

≤6000bottles/hour (Take 100ml water as test)

≤2500bottles/hour (Take 1000ml water as test)

05 Pneumatic (air -operated) source 0.33-0.50 Mpa clean and Stable compressed air
06 Material density: 0.6-1.3
07 Machine weight 480Kg
08 Dimension 2000mm×1100mm×2500mm



16 Head 220 V 60Hz 15A Automatic Liquid SERVO Bottling Piston Filler Multiple filling nozzles as 6, 8, 12 or 20 0

16 Head 220 V 60Hz 15A Automatic Liquid SERVO Bottling Piston Filler Multiple filling nozzles as 6, 8, 12 or 20 1



After-sales Service:
(1) Under stable voltage, the machines' quality that we sold will be guaranteed for 1 year
(2) Long time technology will be supplied.
(3) We can dispatch our engineer to your side for installing and debugging machines. Engineer's round-trip tickets, accommodation, and your side traveling fee will be charged by you. Engineer's salary will be USD60.00/day/person.
We can also supply training process for your engineers who come to china, so you can fit and debug machines by yourself.
